| Type | Electromagnetic Type | Applicable Fluid | Air |
|---|---|---|---|
| Operating Environment | Dust Resistant | Switching Type | Normally Open |
| Connection Type | [Rc (R)] Rc | Plumbing Thread Nominal | 1/4 |
| Driving Type | Linear Motion Type | Tube Dia. | - |
| Orifice Dia.(?) | 5 | Operating Temperature Range(°C) | -20～60 |
| Number of Solenoids | Single Solenoid | Operating Pressure Differential Range(MPa) | null～0.2 |
| Application | Single Item | IP | IP65 |
| Insulation Class | B | Voltage | 24 V DC |
| Sealing materials | NBR | Lead wire exit direction | IN side (standard) |
| Option | None | Body material | Aluminum |
| Bracket | None | Power consumption(W) | 7.5 |
| Functions | None | Lead wire electrical entry | DIN terminal (With surge voltage suppressor) |
| Apparent power(VA) | - | Made to order specifications | - |
